3,000 lbs. Compaction Force Plate Compactor with 6.5 HP 196cc – Pro-Series



Compact gravel, soil, clay, sand and more to create solid foundations that need fewer repairs
3000 lbs. of plate compaction centrifugal force
Travels at 0-50 ft/min, 5,500 blows per minute
Powered by a 6.5HP, 196cc, air cooled, 4-stroke OHV engine with recoil start and low oil shutdown
Compaction depth of 11.8 inches
Plate size 21.25” L x 16.5” W
Noise level 104 dB with no-load
Two-piece, spring loaded handle helps to reduce vibration and fatigue
Handle folds down for compact storage
Back wheels fold up and out of the way
Assembled size: 33” L x 45” H x 17” W
Working surface area: 17” W x 17” H
1-gallon fuel capacity, 20-ounce oil capacity
Powder coat finish and a single piece stamped plate help to keep rust away
Use with Protective Paving Pad model PC3PAD, sold separately
Not recommended for high altitude use above 3,000 ft.
Do not use E85 fuel, this unit is not for use with gasoline/ ethanol blends with over 15 percent ethanol
EPA approved, Non-CARB compliant/Not for sale in California

150 in stock

SKU: PC3000 Categories: , ,


Use the Compaction Force Plate Compactor to pack down soil, sand, crushed gravel or aggregate. This helps to create solid foundations, patios, driveways and walkways. The Pro-Series 3,000 lbs. Compaction Force Plate Compactor has a 6.5 HP engine and delivers 3,000 pounds of force. Plus it offers 5,500 blows per minute to compact nearly any material up to 11.8 inches deep. Easy to move and transport, two rear wheels lock up and out of the way when the Compaction Plate Tamper is in use, and easily fold down when it is time to move to the next job. Protect the bottom surface of the paver from scratches and damage with the 8mm Polyurethane Protective Paving Pad, model PC3PAD, sold separately.

Item # PC3000
